PA6 Injection Grade Virgin-grade Long Glass Fiber Filled PA6 Resin for Electronic Appliances
Dongguan Forever Co.,Ltd is the manufacture of the china origin cheap UV stablized PC polycarbonate Granules Polymer Resin
It is Thermal Conductive Granules Long Glass Fiber Filled Modified PBT Pellet. It has high toughness, high rigidity, high dimensional stability, chemical resistance, good appearance and other characteristics of the product, so they are widely used in car door and window frame, safety toe, mechanical parts, gas nail gun box, professional electric tools,etc
General | ||||
Form | ||||
Filler | ||||
Feature |
| High Mechanical Strength
| Easy Release Good Surface Appearance | |
Usage |
|
|
| |
Physical Nominal Value Test Method | ||||
Density / Specific Gravity 1.37 g/cm³ ISO 1183 | ||||
Water Absorption(23 ℃) 5.5 % ISO 62 | ||||
Moisture Absorption 1.7 % ISO 62 | ||||
Mechanical Nominal Value Test Method | ||||
Tensile Modulus 9500 MPa ISO 527 | ||||
Tensile Strength, Break 180 MPa ISO 527 | ||||
Tensile Elongation, Break 3 % ISO 527 | ||||
Flexural Modulus 8800 MPa ISO 178 | ||||
Flexural Strength 280 MPa ISO 178 | ||||
C harpy Impact Strength, Unnotched(23 ℃) 65 kJ/m² ISO 179 | ||||
C harpy Impact Strength, Notched(23 ℃) 10 kJ/m² ISO 179 | ||||
Thermal Nominal Value Test Method | ||||
Heat Deflection Temperature[HDT](1.8 MPa) 250 °C ISO 75 | ||||
CLTE(Transverse/parallel) 0.2E-4 - 0.6E-4 /K ISO 11359 | ||||
Thermal Conductivity 0.34 W/m-K DIN 52612 | ||||
Flame Rating HB UL 94 | ||||
Electrical Nominal Value Test Method | ||||
Dielectric Constant(1.0e+6 Hz) 3.5 IEC 60250 | ||||
Dissipation Factor(1.0e+6 Hz) 0.014 IEC 60250 | ||||
CTI 450 V IEC 60112 | ||||
Resin PelletsProcessing | Nominal Value |
Melting point DSC | 260 °C |
Melt Temperature Optimum<Injection> | 280 - 300 °C |
Mold temperature range | 80 - 100 °C |
