RFL36-XH compound is a specially formulated material made from Nylon 6 resin with 30% glass fiber and 15% PTFE.
This grade offers excellent resistance to wear and is specifically designed to withstand heavy use and friction.
General | ||||||
Form | Resin Pellets | |||||
Filler | 30 % Glass Fiber | 15 % PTFE | ||||
Feature | Abrasion Resistant | Structural | Internally Lubricated | |||
Usage: Consumer Electrical Building and Construction | ||||||
Physical | Nominal Value | Test Method | ||||
Wear Factor Washer | 12 10^-10 in^5-min/ft-lb-hr | ASTM D3702 Modified: Manual | ||||
Dynamic Cof | 0.59 | ASTM D3702 Modified: Manual | ||||
Density / Specific Gravity | 1.51 g/cm³ | ISO 1183 | ||||
Water Absorption(24 hrs;23 °C) | 1.34 % | ISO 62-1 | ||||
Moisture Absorption(50% RH;23 °C) | 0.46 % | ISO 62 | ||||
Melt Volume Rate, MVR(MVR at 275°C/5 kg) | 15 - 20 cm³/10 min | ISO 1133 | ||||
Mold Shrinkage, Flow(24 hrs) | 0.2 - 0.5 % | ISO 294 | ||||
Mold Shrinkage, XFlow(24 hrs) | 0.8 - 1.2 % | ISO 294 |
Mechanical Nominal Value | Test Method | |
Notched Izod Impact Strength(notched;80*10*3;-40 °C 0)12 kJ/m² | ISO 180/1A | |
Izod Impact, Unnotched(80*10*4;23 °C) 84 kJ/m² | ISO 180/1U | |
Unnotched Izod Impact Strength(unnotched;80*10*4;-4074 kJ/m² °C 0) | ISO 180/1U | |
Izod Impact, Notched(80*10*4;23 °C) 16 kJ/m² | ISO 180/1A | |
Tensile Stress, Break(5 mm/min) 166 MPa | ISO 527 | |
Tensile Strain, Break(5 mm/min) 2.6 % | ISO 527 | |
Flexural Stress, Yield 2 mm/min 2 mm/min;60°C 2 mm/min;100 °C 2 mm/min;150°C 2 mm/min;200°C | 234 MPa 179 MPa 131 MPa 96 MPa 83 MPa | ISO 178 |
Flexural Stress, break(2 mm/min) 277 MPa | ISO 178 | |
Flexural Strain, Break 2 mm/min 2 mm/min;60°C 2 mm/min;100 °C 2 mm/min;150°C 2 mm/min;200°C | 4.1 % 6.1 % 6.6 % 5.6 % 6.3 % | ISO 178 |
Flexural Modulus 2 mm/min 2 mm/min;60°C 2 mm/min;100 °C 2 mm/min;150°C 2 mm/min;200°C | 9100 MPa 5300 MPa 4200 MPa 3500 MPa 3100 MPa | ISO 178 |
