Dongguan Forever Co.,Ltd is the manufacture of the china origin cheap UV stablized PC polycarbonate Granules Polymer Resin
PA6 with 30%GF reinforced, used for the automotive industry, Electrical and Electronics and consumer applications
General | ||
Form Resin Pellets | ||
Filler 30 % Glass Fiber | ||
High Impact Easy Release Excellent Mechanical | ||
Feature High Mechanical Strength | ||
Automotive Industry (interior And Body Parts) | ||
Physical Nominal Value Test Method | ||
Density / Specific Gravity 1.37 g/cm³ ISO 1183 | ||
Water Absorption(23 0 ℃) 6.7 % ISO 62 | ||
Melt Volume Rate, MVR 50 cm³/10 min ISO 1133 | ||
Mechanical Nominal Value Test Method | ||
Tensile Modulus 9500 MPa ISO 527 | ||
Flexural Modulus 8500 MPa ISO 178 | ||
Flexural Strength 270 MPa ISO 178 | ||
C harpy Impact Strength, Unnotched 95 kJ/m² ISO 179 | ||
C harpy Impact Strength, Notched(23 ℃) 10 kJ/m² ISO 179 | ||
Thermal Nominal Value Test Method | ||
Deflection Temperature Under Load, ISO ISO 75 | ||
1.8 MPa 210 °C | ||
0.45 MPa 220 °C | ||
CLTE, Transverse 0.25E-4 - 0.7E-4 /K ISO 11359 | ||
UL temperature rating HB UL 94 | ||
Melting Point(DSC) | 220 °C | |
Processing | Nominal Value | |
Melt Temperature Range | 270 - 290 °C | |
Mold temperature range | 80 - 100 °C |
